| Specifications | |
|---|---|
| Key Features | |
| Capacity | 2048 Wh |
| Output Power | up to 3000 W |
| Charging 0–80% | approx. 45 minutes |
| Battery | LFP (Lithium Iron Phosphate) |
| Lifespan | over 80% capacity after 4000 cycles |
| Expandable Capacity | up to 22,528 Wh |
| Remote Control | via app |
| Charging | AC / solar / car |
| Operation | silent |
| Build | designed for safety, reliability and long-term use |
| Technical Specifications | |
| Model | DYM2000L / DYM2000H |
| Capacity | 2048 Wh |
| Weight | approx. 22 kg |
| Dimensions | 448 × 225 × 324 mm (L × W × H) |
| Maximum Operating Altitude | 5000 m |
| Ports | 4 × AC output, 4 × USB-C, 4 × USB-A, 2 × SDC, 1 × AC input |
| Outputs | |
| AC Output | |
| DYM2000L | AC 100–120 V, 25 A, 50/60 Hz |
| DYM2000H | AC 220–240 V, 13.6 A, 50/60 Hz |
| USB-A Output | |
| Voltage / Current | 5 V / 3 A |
| Voltage / Current | 9 V / 2 A |
| Voltage / Current | 12 V / 2 A |
| Maximum Power | 24 W per channel |
| USB-C Output | |
| Voltage / Current | 5 V / 5 A |
| Voltage / Current | 9 V / 5 A |
| Voltage / Current | 12 V / 5 A |
| Voltage / Current | 15 V / 5 A |
| Voltage / Current | 20 V / 5 A |
| Voltage / Current | 28 V / 5 A (EPR) |
| C1 and C2 | up to 140 W |
| C3 and C4 | up to 65 W |
| SDC Output | |
| SDC 1 and SDC 2 | 9–28 V |
| Maximum Current | 12 A |
| Inputs | |
| AC Input | |
| DYM2000L | AC 110–120 V, max. 15 A |
| DYM2000H | AC 220–240 V, max. 10 A |
| SDC Input | |
| SDC 1 and SDC 2 | DC 32–58.4 V |
| Maximum Current | 60 A |
| Temperatures | |
| Operating | -10 °C to +45 °C |
| Charging | 0 °C to +45 °C |
| Storage | -10 °C to +45 °C |
| Wi-Fi and Bluetooth | |
| Wi-Fi | 2.4000–2.4835 GHz |
| Bluetooth 5.0 | 2.4000–2.4835 GHz |
| Wireless Control | Enables control and management of the power station via wireless connection. |
| Applications | |
| Application | Home Energy Backup |
| Application | Field Power Supply |
| Application | Travel and RVs |
| Application | Video and TV Production |
| Application | Power Supply for Professional Equipment |
| Application | Surveying and Mapping |
| Application | Use in Areas Without Grid Access |
| Package Contents | |
| Contents | 1 × DJI Power 2000 |
